SPECIFICATIONS

Application: Desktop

Back I/O Ports: 1x RJ45

Battery Included: No

Brand Name: XINRENCHONG

Chipset: Intel B360

Chipset Manufacturer: Intel

High-concerned chemical: None

Maximum Ram Capacity: 64 GB

Number of PCI: 3

Onboard LAN: 1x RJ45

Origin: Mainland China

PCI - E standards: PCI-E 3.0

Package: No

Processor compatibility: 9th Intel Core i5,9th Intel Core i7

RAID Supported: No

Socket Type: LGA 1151

Special Features: NONE

Storage Interface Type: SATA 3

Support Memory Type: DDR4

Usage Scenario: Enthusiast & Overclocking,Gaming,Audio & Video,Office

With CPU: No

Category Specification Details

Main Chipset Intel B360, LGA1151 v2 socket

Processor Support 8/9th generation Core i9/i7/i5/i3 / Celeron / Pentium (BIOS support required)

Power Supply Design Mixed digital PWM, 8+24pin power interface

Memory 4×DDR4 DIMM, dual-channel, up to 64GB; 2133/2400/2666MHz (XMP requires 8/9th generation Core)

Storage 2×M.2 (M-key, PCIe 3.0 x4/x2 or SATA, 2242/2260/2280/22110); 6×SATA 6Gbps (RAID 0/1/5/10)

Expansion Slots 1×PCIe 3.0 x16 (x16); 1×PCIe 3.0 x16 (x4); 4×PCIe 3.0 x1

Network / Audio Intel GbE Gigabit Network Card (cFosSpeed); Realtek ALC892 7.1 Channel, S/PDIF Output

Video Output 1×DVI-D (1920×1200@60Hz); 1×HDMI 1.4 (4096×2160@30Hz, HDCP 2.2)

USB External: 1×USB 3.1 Gen2 Type-C, 1×USB 3.1 Gen2 Type-A, 2×USB 3.1 Gen1; Internal: 1×USB 3.1 Gen1 Pin, 2×USB 2.0 Pin

Form Factor / Size ATX, 30.5×22.5cm

Special Features RGB Fusion 2.0, Smart Fan 5, CNVi Wireless Expansion Slot, Anti-Sulfur Resistance, TPM Header

Wireless No onboard WiFi / Bluetooth, can add Intel CNVi Wireless Network Card
